Unlike surfaces or faces, you cannot export individually selected model edges to an IGES file. You can also select Bounded Surface (type 143).Ĭonverts the solid body to a 3D wireframe representation in the IGES file. Select Manifold Solid (type 186) to export boundary representation (BREP) data to the IGES file. Select Trimmed Surface (type 144) to convert the faces of the part, assembly, or the selected surfaces to trimmed surfaces in the IGES file. Select from the options described below, then click OK.Įxports the data as solid or surface entities.
Note: Mastercam and Mastercam for SOLIDWORKS must be shut down for the update to install properly.The IGES translator supports layers when you export an assembly document as an IGES file. O Start 2017 and select Update Mastercam from the Help menu. O Manually check for updates from the Windows Start menu – Start > Mastercam 2017 or Mastercam 2017 for SOLIDWORKS> Check for Updates and then follow the instructions. Click on this to activate the Update Manager. O Start 2017 and a Mastercam update bubble will show in the lower right of your screen in the system tray area. Use one of the 3 methods listed below to perform an update. For a detailed list of what issues have been addressed in 2017 Update 1 please see the Read Me files. There will not be a full install available, only the patch update. This is a Mastercam and Mastercam for SOLIDWORKS only update. The 2017 Update 1 downloads will also be available on the Product Downloads section of the website at. This update installs directly on top of 2017 release and is available through the Update Manager. Fore documentation of items addressed refer to the Mastercam Update 1 Readme or Mastercam for SOLIDWORKS Update 1 Readme. This release addresses software defects identified since the initial release of Mastercam 2017. CNC Software has released both the Mastercam and Mastercam for SOLIDWORKS 2017 Update 1.
